2025 MOVAX TAD-32

MOVAX TAD-32 Telescopic Piling Drill

Technical Specifications

General:
- Drilling depth: 9 m
- Weight: 3,200 kg
- Height: 3,855 mm

Hydraulics:
- Oil flow rate: 75–250 l/min
- Oil pressure: 350 bar

Drilling Capacity:
- Hole diameter: 400–1,000 mm
- Drill speed range: 11–74 rpm
- Torque: 30 kNm
- Side tilt angle: ±30°

Performance:
- Extraction force: 30 kN
- Crowd force: 15 kN

Carrier Requirements:
- Excavator class: 24–35

Lead Augers
- Outer diameter: 400–1,000 mm
