2023 JSIE JSIE9390TJZZ

·40FT Tri-Axle Wing Van semi trailer:
Feature：Carry Soft Drinks
Dimension(L*W*H): 12210*2590*2900mm
Axle Space：8340+1350+1350mm
Main frame:：Heavy duty and extra durability design; Opting for high tensible low carbon alloy Q345B steel; I beam welded by automotive arc-submerge process
Model: JS9390TJZZ
Wing Van：Alloy Aluminum Plate
No. of axle：3
Payload(kgs)：40000
Tare weight(kgs)：8950
Kingpin：The world-famous JOST brand bolt-in/welded type 3.5"/2"
Landing gear：JOST brand two-speed manual operation 19"
Tire size：11R22.5,12R22.5,315/80R22.5,385/65R22.5
Rim size：8.25*22.5,9.00*22.5,11.75*22.5
Axle：Original BPW-12T/ FUWA-13T
Suspension Germany type with 12pcs of leafs spring/ Fuwa brand with 8pcs of leafs spring
Brake system：Dual line with WABCO brand Re-6 emergency relay valve, MBA brand T30/30 air chamber, 46L air tank
Electric system: One unit of 24V 7-pin ISO standard socket; with brake light, turn light, reverse light, side light, reflector, fog light; one set of 6-pin standard cable
Height of Siding：600mm or optional
Control System：Hydraulic Manual Operation
Painting：S.A.2.5 standard sandblasting; Two coat of anti-corrosion prime; one coat of finish painting
Accessory：One tool box; one set of standard tool
