XCMG XGC11000
Condition
Used
1
of
8
XCMG XGC11000
1
of
8
Overview
Description
XCMG 2021 year used Lifting Machinery XGC11000 Factory price
Model Number: XGC11000
Brand Name: XCMG
Place of Origin: Jiangsu
Max. Lifting Height: 96 m
Max. Lifting Load: 650 ton
Rated Loading Capacity: 650 ton
Application: Construction
weight: 650000.000kg
Moving Type: Other
Year: 2021/1/19
Work hours: 3571h
: 7 days for ready goods
: 1 Piece
: Any Port In China
ItemUnitParameter
Parameter item-XGC11000
Performance parameters
Main boon rated liad(t)650
Fixed jib rated lifting weight(t)330
Luffing jib maximum rated lifting weight(t)240
Max Lifting Moment(t.m)10800
Tower jib maximum lifting weight(t)230
Working condition of single arm end pulley maximum rated lifting weight(t)170
Dimension parameter
Main boom length(m)24~96
The main luffing Angle(°)30~84
Fixed jib length(m)66~108
Tower jib length(m)30-66
Operating dimension(L*W*H)(m)12×3.3×3.4
Fixed jib installation Angle(°)
Special deputy arm length(m)48-108+24-96
Speed parameter
The biggest single rope hoist speed(m/min)130
The boom luffer maximum speed of single rope(m/min)2*56
Deputy arm luffing mechanism's largest single rope speed(m/min)130
Maximum turning speed(r/min)0.7
XCMG 2021 year used Lifting Machinery XGC11000 Factory priceModel Number: XGC11000
Brand Name: XCMG
Place of Origin: Jiangsu
Max. Lifting Height: 96 m
Max. Lifting Load: 650 ton
Rated Loading Capacity: 650 ton
Application: Construction
weight: 650000.000kg
Moving Type: Other
Year: 2021/1/19
Work hours: 3571h
: 7 days for ready goods
: 1 Piece
: Any Port In China
ItemUnitParameter
Parameter item-XGC11000
Performance parameters
Main boon rated liad(t)650
Fixed jib rated lifting weight(t)330
Luffing jib maximum rated lifting weight(t)240
Max Lifting Moment(t.m)10800
Tower jib maximum lifting weight(t)230
Working condition of single arm end pulley maximum rated lifting weight(t)170
Dimension parameter
Main boom length(m)24~96
The main luffing Angle(°)30~84
Fixed jib length(m)66~108
Tower jib length(m)30-66
Operating dimension(L*W*H)(m)12×3.3×3.4
Fixed jib installation Angle(°)
Special deputy arm length(m)48-108+24-96
Speed parameter
The biggest single rope hoist speed(m/min)130
The boom luffer maximum speed of single rope(m/min)2*56
Deputy arm luffing mechanism's largest single rope speed(m/min)130
Maximum turning speed(r/min)0.7
Model Number: XGC11000
Brand Name: XCMG
Place of Origin: Jiangsu
Max. Lifting Height: 96 m
Max. Lifting Load: 650 ton
Rated Loading Capacity: 650 ton
Application: Construction
weight: 650000.000kg
Moving Type: Other
Year: 2021/1/19
Work hours: 3571h
: 7 days for ready goods
: 1 Piece
: Any Port In China
ItemUnitParameter
Parameter item-XGC11000
Performance parameters
Main boon rated liad(t)650
Fixed jib rated lifting weight(t)330
Luffing jib maximum rated lifting weight(t)240
Max Lifting Moment(t.m)10800
Tower jib maximum lifting weight(t)230
Working condition of single arm end pulley maximum rated lifting weight(t)170
Dimension parameter
Main boom length(m)24~96
The main luffing Angle(°)30~84
Fixed jib length(m)66~108
Tower jib length(m)30-66
Operating dimension(L*W*H)(m)12×3.3×3.4
Fixed jib installation Angle(°)
Special deputy arm length(m)48-108+24-96
Speed parameter
The biggest single rope hoist speed(m/min)130
The boom luffer maximum speed of single rope(m/min)2*56
Deputy arm luffing mechanism's largest single rope speed(m/min)130
Maximum turning speed(r/min)0.7
