Application:
It is mainly used in situations where the working site is small, the ground is uneven, and the work content changes frequently. It is suitable for infrastructure construction, Industrial applications, dock loading and unloading, urban streets, residential buildings, barns, livestock sheds, airport runways, etc. It can also be used as auxiliary equipment for large-scale engineering construction machinery.
Feature:
1. Compact and agile, facilitating operations in small terrains and confined spaces.
2. Convenient to operate and easy to transport;
3. Constructed from high-quality, thickened steel and treated with a powder-coating process for superior rust and corrosion resistance.
4. With 360-degree body rotation, its agile chassis brings convenience to outdoor operations.
Main Technical Parameters:
Engine:
Engine model: RATO 740 Gasoline Engine
No. of cylinders: 2
Rated Power: 15 kW
Performance:
Operating height: 2450 mm
Height to bucket hinge pin: 1870 mm
Overall height: 1360 mm
Overall length with GP bucket: 2206 mm
Overall length without bucket: 1680 mm
Wheel base: 850 mm
Overall width: 1050 mm
Min. ground clearance: 150 mm
Max. dumping height: 1410 mm
Rated load: 300 kg
Rate bucket capacity: 0.12 m³
Bucket width: 1050 mm
Track width: 180 mm
Operating weight: 1000 kg
Operating system pressure: 17 bar
Fuel tank capacity: 10 L
Travel speed: 0-5 km/h
Note:
1. Technical specifications are for standard model (without cabin) only.
2. Other optional parts & accessories and colors are available upon request.
3. All specifications and design characteristics are subject to change without prior notice.
