2024 Caterpillar 950GC

Medium wheel loaders

950 GC

Main technical specifications

Net Power - ISO 9249

151 kW

Operating weight

18676 kg

Bucket capacity

2.5-4.4 m³（3.3-5.75 yd³）

Engine

Net Power - ISO 9249 151 kW

cylinder diameter 105 mm

stroke 135 mm

engine

Engine model Cat C7.1

displacement 7.01 l

Maximum Gross Torque - 1400 rpm 1020 N·m

Rated Net Power - 2200 rpm - ISO 9249 151 kW

Rated Gross Power - 2200 rpm - ISO 14396 168 kW

Maximum Gross Power - 2000 rpm - ISO 14396 171 kW

Maximum Net Torque - 1300 rpm 931 N·m

weight

Operating weight 18676 kg

bucket

Bucket capacity 2.5-4.4 m³（3.3-5.75 yd³）

Operating specifications

digging force 147 kN

Note (1) Conforms to ISO (2007) 14397-1 parts 1 to 5.

Static Tipping Load - 40° Full Turn - Rigid Tires 11197 kg

Static Tipping Load - 40° Full Turn - ISO 14397-1* 10503 kg

Note (2) *Fully compliant with ISO (2007) 14397-1 Parts 1 to 6, which requires a 2% maximum error between calculated and tested results.

gearbox

Forward - 1st 7 km/h

Forward - 2nd 12.5 km/h

Forward - 3rd 22 km/h

Forward - 4th 34 km/h

Reverse - 1st gear 7 km/h

Reverse - 2nd 12.5 km/h

Reverse - 3rd 22 km/h

hydraulic system

Steering System - Pump Type piston

Hydraulic Cycle Time - Dump at Maximum Lift 1.2 s

Hydraulic Cycle Time – Total Cycle Time 10.1 s

Hydraulic Cycle Time – Lower, No Load and Float Lower 2.8 s

Hydraulic Cycle Time - Lift from Carry Position 6.1 s

Implement System - Optional 3rd Function Maximum Flow 280 l/min

Implement System - Maximum Pump Displacement at 2200 rpm 248 l/min

Implement System Pump Type piston

Implement System - Maximum Operating Pressure at 50 ± 1.5 L/min (13.2 + 0.4 gal/min) 27900 kPa

Implement System – Optional 3rd Function Maximum Pressure at 70 L/min 20680 kPa

brakes

brakes Brakes comply with ISO 3450

tire

choose Options include: 23.5-25 16PR, L3 (Triangle); 23.5R25, L3 (Triangle); 23.5R25, L3 (Bridgestone)

Cab

ROPS/FOPS ROPS/FOPS complies with ISO 3471 and ISO 3449 Class II standards

Maintenance refill capacity

Differential - Final Drive - Front 40 l

crankcase 20 l

Fuel tank size 290 l

Differential - Final Drive - Rear 38 l

gearbox 45 l

Hydraulic oil tank 120 l

Cooling system 48 l

size

B-pin height 4188 mm

B-Pin Height - Carry Position 655 mm

Lift arm clearance 3649 mm

Rear axle centerline to counterweight edge 2001 mm

Height - Top of ROPS 3458 mm

Height - Top of Exhaust Pipe 3596 mm

Height - Top of Hood 2568 mm

wheelbase 3300 mm

Rear axle centerline to hitch 1650 mm

Bucket tilt angle - maximum lift 60°

Dump angle at maximum lift position 52°

Rack Angle - Carrying 45°

Backward Angle - Ground Position 40 °

Height - Axle Centerline 750 mm
