5sاكس سي ام جي XCA220
اكس سي ام جي XCA220
حالة المعدة
مستعملة
١
من
٩
اكس سي ام جي XCA220
١
من
٩
نظرة عامة
الوصف
XCMG All Terrain 220ton XCA220 2021 Used Truck Cranes For Sale
Certification: CE/IOS9001
Model Number: XCA220
Brand Name: XCMG
Place of Origin: Xuzhou, China
Span: 7.6m
Max. Lifting Height: 73.5m
Max. Lifting Load: 220ton
Rated Lifting Moment: 7393kN.m
Rated Loading Capacity: 220ton
Application: Construction
Weight: 55000.000kg
Moving Type: Other
Dimensions: 13900*2800*3675mm
Max. travel speed: 84km/h
Maximum climb: 67%
Engine rated torque: 2200/1300N.m/(r/min)
Engine rated power: 361.1/1800 kw/(r/min)
Whole length 15500 (mm)
Full width of the whole machine 2980 (mm)
Whole machine high 3930 (mm)
Wheelbase 2650+1650+2500+1650 (mm)
Tread 2590 (mm)
General quality of running state 55000 (kg)
Axle load 12000×3+9500×2 (kg)
Engine model (on the bus) OM460LA.E3B/3 -
Engine rated power 361.1/1800 (kw/(r/min))
Engine rated torque 2200/1300 (N.m/(r/min))
Engine model (get off) — -
Engine rated power — (kw/(r/min))
Engine rated torque — (N.m/(r/min))
Maximum travel speed 84 (km/h)
Minimum stable running speed 1~1.5 (km/h)
Minimum turning diameter 18.5 (m)
Minimum turning diameter 22.5 (m)
Maximum climb 67 (%)
Minimum ground clearance 280 (mm)
Approach angle 18 (°)
Departure angle 14 (°)
Maximum rated total weight 220 (t)
Minimum rating 3 (m)
Maximum lifting torque of the basic arm 7393 (kN·m)
Turning radius 5030 (mm)
XCMG All Terrain 220ton XCA220 2021 Used Truck Cranes For SaleCertification: CE/IOS9001
Model Number: XCA220
Brand Name: XCMG
Place of Origin: Xuzhou, China
Span: 7.6m
Max. Lifting Height: 73.5m
Max. Lifting Load: 220ton
Rated Lifting Moment: 7393kN.m
Rated Loading Capacity: 220ton
Application: Construction
Weight: 55000.000kg
Moving Type: Other
Dimensions: 13900*2800*3675mm
Max. travel speed: 84km/h
Maximum climb: 67%
Engine rated torque: 2200/1300N.m/(r/min)
Engine rated power: 361.1/1800 kw/(r/min)
Whole length 15500 (mm)
Full width of the whole machine 2980 (mm)
Whole machine high 3930 (mm)
Wheelbase 2650+1650+2500+1650 (mm)
Tread 2590 (mm)
General quality of running state 55000 (kg)
Axle load 12000×3+9500×2 (kg)
Engine model (on the bus) OM460LA.E3B/3 -
Engine rated power 361.1/1800 (kw/(r/min))
Engine rated torque 2200/1300 (N.m/(r/min))
Engine model (get off) — -
Engine rated power — (kw/(r/min))
Engine rated torque — (N.m/(r/min))
Maximum travel speed 84 (km/h)
Minimum stable running speed 1~1.5 (km/h)
Minimum turning diameter 18.5 (m)
Minimum turning diameter 22.5 (m)
Maximum climb 67 (%)
Minimum ground clearance 280 (mm)
Approach angle 18 (°)
Departure angle 14 (°)
Maximum rated total weight 220 (t)
Minimum rating 3 (m)
Maximum lifting torque of the basic arm 7393 (kN·m)
Turning radius 5030 (mm)
Certification: CE/IOS9001
Model Number: XCA220
Brand Name: XCMG
Place of Origin: Xuzhou, China
Span: 7.6m
Max. Lifting Height: 73.5m
Max. Lifting Load: 220ton
Rated Lifting Moment: 7393kN.m
Rated Loading Capacity: 220ton
Application: Construction
Weight: 55000.000kg
Moving Type: Other
Dimensions: 13900*2800*3675mm
Max. travel speed: 84km/h
Maximum climb: 67%
Engine rated torque: 2200/1300N.m/(r/min)
Engine rated power: 361.1/1800 kw/(r/min)
Whole length 15500 (mm)
Full width of the whole machine 2980 (mm)
Whole machine high 3930 (mm)
Wheelbase 2650+1650+2500+1650 (mm)
Tread 2590 (mm)
General quality of running state 55000 (kg)
Axle load 12000×3+9500×2 (kg)
Engine model (on the bus) OM460LA.E3B/3 -
Engine rated power 361.1/1800 (kw/(r/min))
Engine rated torque 2200/1300 (N.m/(r/min))
Engine model (get off) — -
Engine rated power — (kw/(r/min))
Engine rated torque — (N.m/(r/min))
Maximum travel speed 84 (km/h)
Minimum stable running speed 1~1.5 (km/h)
Minimum turning diameter 18.5 (m)
Minimum turning diameter 22.5 (m)
Maximum climb 67 (%)
Minimum ground clearance 280 (mm)
Approach angle 18 (°)
Departure angle 14 (°)
Maximum rated total weight 220 (t)
Minimum rating 3 (m)
Maximum lifting torque of the basic arm 7393 (kN·m)
Turning radius 5030 (mm)
