2023 كاتربيلر 305.5E

1. Engine:
Model: Cat C2.4 DI
Net Power: 31.1kW (41.7hp)
Gross Power - 2400rpm - SAE J1995: 34.1kW (45.7hp)
Net Power - 2400rpm - ISO 9249/SAE J1349: 31.1kW (41.7hp)
Displacement: 2.4L
Bore: 87mm
Stroke: 102.4mm

2. Operating Weight: 5400kg

3. Dimensions:
Ground Clearance: 628mm
Track Length: 2440mm
Shipping Height: 2540mm
Transport Width: 1950mm
Tail Swing Radius: 1580mm
Track Gauge: 1550mm
Length - Roller Center: 1920mm
Shoe Width: 400mm
Shipping Length: 5765mm

4. Hydraulic system:
Working pressure - equipment: 25000kPa (3626psi)
Working pressure - travel: 25000kPa (3626psi)
Working pressure - swing: 21600kPa (3133psi)
Digging force - bucket: 35kN (7868lbf)
Digging force of bucket arm: 27.2kN (6115lbf)
Type: Load sensing hydraulic system with variable displacement piston pump

5. Swing system:
Swing torque: 13.9N·m (10.3lb/ft)
Machine swing speed: 10.5min-1

6. Oil capacity:
Cooling system: 9.8L (2.6gal (US))
Engine oil: 9.5L (2.5gal (US))
Hydraulic oil tank: 58L (15.3gal (US))
Fuel tank: 78L (20.6gal (US))
Hydraulic system: 85L (22.5gal (US))

7. Operating range:
Maximum reach - ground: 5830mm (19.1ft)
Maximum reach: 5955mm (19.5ft)
Maximum depth: 3720mm (12.2ft)
Maximum digging height: 5460mm (17.9ft)
Maximum dump height: 3835mm (12.6ft)
Maximum vertical digging height: 2210mm (7.3ft)

8. Boom and arm length:
Boom length: 3200mm (126in)
Arm length: 1500mm (59.1in)

9. Others:
Gradability - Maximum: 25°
Maximum traction - High speed: 40.2kN (9037lbf)
