2020 كاتربيلر 308E2

specifications
Tonnage (ton): 8
Working weight of the whole machine (kg): 7160
Bucket capacity (m ³): 0.38
Arm length (mm): 3700
Rod length (mm): 1820
Bucket width (mm): 949
Power: Traditional Power
Manufacturer: Joint Venture/Import
Bucket: Backhoe
dynamical system

Engine model: Cat C3.3 DI Turbo
Rated power (kw/rpm): 46/2000
Cylinder diameter x stroke (mm): 94 * 120
Displacement (L): 3.33
performance

Rotation speed (rpm): 10.8
Climbing ability (%): 70
Bucket excavation force (kN): 57.1
Excavating force of boom (kN): 38.9
Maximum Traction Force (kN): 56.9
Walking speed (km/h): 3.2-5.1
Rotation torque (Nm): 16.3

Maximum unloading height: 3900 mm 36
Fuel and maintenance capacity
Fuel tank: 78 L 36
Hydraulic oil tank: 58 L 36
Engine oil change quantity: 9.5 L 36
Coolant capacity: 8.3 L 3
Other performance
Driving speed: 2.8 km/h (low speed), 4.3 km/h (high speed) 26
Climbing ability: ≥ 50% 29
Applicable altitude: up to 2500 meters
