2018 هيتاشى ZX200-3G

Used Excavator Hitachi ZX200-3G in Shanghai RONGQUAN Machinery Co.,ltd

Operating weight of the whole machine: 19.8 tons. ‌‌
Bucket capacity: 0.91 cubic meters. ‌‌
Ground voltage ratio: 44KPa. ‌‌
Overall dimensions: 9.5 meters (length) x 2.86 meters (width) x 2.97 meters (height). ‌‌
Engine parameters.
Model: Isuzu AA-6BG1T direct injection engine. ‌‌
Rated power: 110 kW (147 horsepower)/2100 rpm. ‌‌
Number of cylinders: 6 cylinders, displacement 6.494 liters. ‌‌
Hydraulic system.
Main pump type: Variable axial piston pump x 2, maximum flow rate 194L/min x 2. ‌‌
Working hydraulic oil circuit pressure: 34.3MPa. ‌‌
Hydraulic oil tank capacity: 135 liters, total system oil volume 240 liters. ‌‌
Scope of homework.
Maximum excavation radius: 9910 millimeters. ‌‌
Maximum excavation depth: 6660 millimeters. ‌‌
Maximum unloading height: 6790mm. ‌‌
